Surface Dressing Binders

Premium 80

Premium 80 is a BBA HAPAS approved premium grade polymer modified cationic bitumen emulsion.

Make an enquiry

Introduction

By using selected emulsifying agents with a suitable emulsion grade penetration bitumen it has been specifically designed for use as a hot applied surface dressing binder.

Where to use?

Premium 80 is suitable for use on higher stressed, heavier trafficked sites as a premium grade surface dressing binder as specified in the Design Guide for Road Surface Dressing, Road Note 39.

Preparation

Please refer to the Road Surface Treatment Association’s (RSTA)/ADEPT Code of Practice for Surface Dressing Part 5 – Surface Preparation.

Application

Premium 80 should be applied at a temperature of 85°C through a bulk binder distributor which has been tested for compliance with BS 1707 (hot binder distributors for surface dressing).

The surface dressing works should be in accordance with the recommendations contained in Design Guide for Road Surface Dressing, Road Note 39 and the RSTA’s Codes of Practice for Surface Dressing.

Due to high residual binder viscosity, optimum results are obtained with Premium 80 during the warmer months of May to August.

Coverage

Refer to the Design Guide for Road Surface Dressing, Road Note 39 or contact your local Colas depot or representative for further guidance.

Packaging

Supplied in bulk loads.

Storage

Premium 80 should be stored at 85°C in a purpose-built bulk storage tank or spray tanker and circulated daily.

Standards

Premium 80 is a CE Marked cationic bitumen emulsion to BS EN13808:2013 C70BPF2/3/4.

Premium 80 complies with the requirements of Road Note 39, Design Guide for Road Surface Dressing as a Premium Grade surface dressing binder.

Emulsion

Efflux 4 mm @ 40ºC (EN 12846-1) 5 – 70 s (Class 5)
Water effect on binder adhesion (EN 13614) ≥ 90 (Class 3)
Water effect on binder adhesion (EN 13614)

< 110 – 195 (Class 2/3/4)

Recovered Binder

Penetration @ 25ºC (EN 1426) ≤ 220 (Class 5)
Softening point (EN 1427) ≥ 46ºC (Class 5)
Cohesion by pendulum (EN 13588) ≥ 1.2 J/cm² (Class 3)

Stage 1 Durability - Stabilised Binder

Durability of penetration @ 25ºC (EN 1426) NPD
Durability of softening point (EN 1427) NPD

Durability of cohesion by pendulum

(EN 13588)
NPD


Stage 2 Durability - Aged Binder

Durability of penetration @ 25ºC (EN 1426) NPD
Durability of softening point (EN 1427) NPD

Durability of cohesion by pendulum

(EN 13588)
NPD
Dangerous regulated substances NPD





Safety

For full safety information, please download the Premium 80 Safety Data Sheet 16 in the link available below on this page.
CE Marking Information C5 Premium 80, Declaration of Performance C5 Premium 80 and
BBA HAPAS H162PS1i2 - Bitumen Road Emulsions Certificate documents are also available to download on this page.
For further information please contact us using the contact details provided on the page.
